Page 7 - UVPure_NewGen_Packet_210218

Product Line

Feature comparison
Effective August 1, 2019

Hallett
Hallett Upstream Hallett Hallett
st
rd
rd
Feature 1 Generation 2 Generation 3 Generation 3 Generation
nd
H30, H13 H15xs, NC series H500, H750 series H1000 series
Crossfire Technology Built in Built in Built in Built in
>> Eliptical Reflectors, >> 360⁰ Disinfection Built in Built in Built in Built in
>> Dual Lamps, >> Multiple Sensors Built in Built in Built in Built in
>> Self cleaning mechanism Built in Built in Built in Built in
Touch screen Touch screen
User Interface Single button Four mechanical buttons
Color Color
Dual Dual Dual Dual
Operational alarms
visual - audible visual - audible visual - audible visual - audible
Touch screen Touch screen
Display - Liquid Crystal (LCD) Optional Built in
Color Color
4-20 mA output 4-20 mA output
Communications 4-20 mA output Not available
Modbus Modbus
UV Intensity Warning Dry Contact NA NA Built in Built in
Remote Start/Stop NA NA Built in Built in
Built-in Surge Protection Optional Optional Built in Built in
Message History NA Last 50 messages Last 99 messages Last 99 messages
Data logging - local NA NA Optional Optional
Flow range up to 51 USgpm up to 51 USgpm up to 51 USgpm up to 100 USgpm
2
(@ 40 mJ/cm , 95% UVT) 193 L/min 193 L/min 193 L/min 378 L/min
Minimum UVT required 45% 50% 50% 35%
Lamp Type LPHO LPHO LPHO Amalgam
Lamp Expected Life 9000 hours 9000 hours 9000 hours 9000 hours
Lamp Heaters NA NA Available Available
Time Needed for Lamp Change 5 minutes < 5 minutes < 2 minutes < 2 minutes
Digital technology Digital technology
Sensor Design Analog technology Digital technology
NIST compliant NIST compliant
One per lamp
Dual Sensors One per unit One per unit One per unit
2 per unit
Improved Improved
Convection cooling Forced air cooling
Temperature Control forced air cooling forced air cooling
Optional purge valve Built-in purge valve
Built-in purge valve Built-in purge valve
Third party US EPA UVDGM
Performance Validation Factory Tested Factory Tested
Validation (1) Validated
NSF/ANSI 55 NSF/ANSI 55 NSF/ANSI 55
Drinking Water Performance Certification NWRI / Validation
Class A Class A Class A
Drinking Water System Components – NSF/ANSI/CAN 61 NSF/ANSI/CAN 61 NSF/ANSI/CAN 61 & 372 NSF/ANSI/CAN 61 & 372
Health Effects / Lead Free Compliance certified certified certified certified
Drinking Water and Water Reuse Factory Tested Factory Tested Factory Tested NWRI Validation
Performance Validation
(1) Pending
(2) NA - Not available

v.20210218
