ACID AND ALKALI PUMP

CHEMICAL PUMP MOTOR

耐酸碱泵化⼯泵电机

IM B14A/V18 H71-132安装尺⼨ /Installation size

安装尺⼨ 外形尺⼨
机座号 (Mounting dimension)
Frame Overall dimension
Size AC AD D E KK HD L M N P S T
71 135 86 14 30 M16X1.5 155 250 85 70 105 M6 2.5

80 148 96 19 40 M20X1.5 170 295 100 80 120 M6 3

90 166 115 24 50 M25X1.5 196 350 115 95 140 M8 3
100 191 128 28 60 M25X1.5 222 385 130 110 160 M8 3.5 1. 适⽤于以下耐酸碱泵⼯况: 1. Applicable to the following acid and alkali pump working
conditions:Adaptable to a wide range of industries, such as
适应区域⼴泛，如、冶⾦、电⼒、造纸、⻝品、制药、合成纤维等⼯业
112 212 140 28 60 M25X1.5 245 415 130 110 160 M8 3.5 metallurgy, electricity, paper, food, pharmaceutical, synthetic fiber
部⻔⽤于输送腐蚀性的或不允许污染的介质；化学液体、废液处理、 and other industrial sectors for transporting corrosive or non-
132 258 163 38 80 M25X1.5 290 510 165 130 200 M10 3.5 酸性、⼯业液体及作紧急、备⽤或过滤之⽤途；印刷电路板、半导 contaminating media; chemical liquids, waste liquid treatment,
acid, industrial liquids and emergency, standby Or the purpose of
体、电镀加⼯、⾦属表⾯精饰、冲晒处理、⽔及废⽔处理.
filtration; printed circuit boards, semiconductors, electroplating,
2.电机效率⾼，效率可以达到IEC 60034-30:2014的IE2等级和GB metal surface finishing, rinsing, water and wastewater treatment.
18613-2012的3级能效。 2. The motor efficiency is high, and the efficiency can reach the IE2
level of IEC 60034-30:2014 and the level 3 energy efficiency of GB
3.电机铁⼼采⽤冷轧矽钢⽚，F级绝缘，耐热温度⾼，抗冲击性强，绝 18613-2012.
缘使⽤寿命⻓。 3. The motor core adopts cold-rolled silicon steel sheet, F-class
4.电机外壳采⽤铸铁，结构稳定、振动⼩、噪声低，性能稳定、安全可靠。 insulation, high heat resistance temperature, strong impact
resistance and long service life of insulation.
4. The motor casing is made of cast iron, which has stable structure,
low vibration, low noise, stable performance, safety and reliability.

海拔不超过1000m；(⼤于1000m海拔属于⾼原电机，可定制) The altitude does not exceed 1000m; (more than 1000m altitude
最⾼环境温度不超过40℃； belongs to the plateau motor, can be customized)
The maximum ambient temperature does not exceed 40 °C;
最低环境温度不超过15℃；
The minimum ambient temperature does not exceed -15 °C;
IM B5/V1 H132-160安装尺⼨ /Installation size S1⼯作制； S1 working system;
电源电压波动不超过±5%(短时允许10%)；频率波动不超过±2%； The power supply voltage fluctuation does not exceed ± 5% (10%
is allowed for short time); the frequency fluctuation does not
安装尺⼨ 外形尺⼨ 绝缘等级F级；
机座号 (Mounting dimension) exceed ± 2%;
Frame Overall dimension 防护等级：IP54、IP55； Insulation class F;
Size AC AD D E KK HD L M N P S T 冷却⽅式：IC411； Protection level: IP54, IP55;
Cooling method: IC411;
132 258 163 38 80 M25X1.5 313 510 265 230 300 14.5 4

160 313 191 42 110 M25X1.5 366 665 300 250 350 18.5 5
