SPECIAL MOTOR FOR

WOODWORKING

⽊⼯专⽤电机

品质四福 动力无限
Quality Sifu Unlimited Power

1.⽊⼯电机专为⽊⼯设备⽽设计，如台锯，刨床等。 1. Woodworking motor is specially designed for woodworking
equipment, such as table saw, planer, etc.
2.电机铁⼼采⽤冷轧矽钢⽚，F级绝缘，耐热温度⾼，抗冲击性强，绝
2. The motor core adopts cold-rolled silicon steel sheet with class F
缘使⽤寿命⻓。 insulation, high heat resistance temperature, strong impact
3.电机外壳采⽤拉伸铝合⾦，电机散热性好，端盖采⽤铸铁，结构稳 resistance and long insulation service life.
3. The motor shell is made of stretched aluminum alloy, with good
定、振动⼩、噪声低，性能稳定、安全可靠。
heat dissipation. The end cover is made of cast iron, with stable
4.超⾼的击穿扭矩，最⼤切割功率。 structure, low vibration, low noise, stable performance, safety and
5.IP65防护等级，防⽌⽊屑和刨花引起的粉尘问题 reliability.
4. Ultra high breakdown torque and maximum cutting power.
5. IP65 protection grade to prevent dust problems caused by wood
chips and shavings

海拔不超过1000m；(⼤于1000m海拔属于⾼原电机，可定制) The altitude does not exceed 1000m; (more than 1000m altitude
最⾼环境温度不超过40℃(＞40℃可定制)； belongs to the plateau motor, can be customized)
The maximum ambient temperature does not exceed 40 °C;
最低环境温度不超过15℃(低于-15℃可定制)；
The minimum ambient temperature does not exceed -15 °C;
S1⼯作制； S1 working system;
电源电压波动不超过±5%(短时允许10%)；频率波动不超过±2%； The power supply voltage fluctuation does not exceed ± 5% (10%
is allowed for short time); the frequency fluctuation does not
绝缘等级F级；
exceed ± 2%;
防护等级：IP65； Insulation class F;
冷却⽅式：IC411； Protection level: IP65;
Cooling method: IC411;

技术数据(Technical Data)

额定功率 电 压 频率 额定功率 额定转速 效 率 功率因数 额定转矩 堵转转矩 最⼤转矩 堵转电流 重 量
型 号 Rated Voltage Frequency Rated Rated Efficiency Power Rated 倍数 倍数 倍数 Weight
Type Output Current Speed η factor Torque kg
kW V Hz A min -1 % COSφ Nm Ts/Tn Tmax/Tn Is/In
YM-634-4 0.37 380 50 1.15 1330 66.0 0.74 2.66 2.1 2.2 4.4 5.3
