SPECIAL MOTOR FOR


        WOODWORKING

        ⽊⼯专⽤电机










                     品质四福  动力无限
                    Quality Sifu  Unlimited Power











        1.⽊⼯电机专为⽊⼯设备⽽设计，如台锯，刨床等。                            1.  Woodworking  motor  is  specially  designed  for  woodworking
                                                            equipment, such as table saw, planer, etc.
        2.电机铁⼼采⽤冷轧矽钢⽚，F级绝缘，耐热温度⾼，抗冲击性强，绝
                                                            2. The motor core adopts cold-rolled silicon steel sheet with class F
        缘使⽤寿命⻓。                                             insulation,  high  heat  resistance  temperature,  strong  impact
        3.电机外壳采⽤拉伸铝合⾦，电机散热性好，端盖采⽤铸铁，结构稳                     resistance and long insulation service life.
                                                            3. The motor shell is made of stretched aluminum alloy, with good
        定、振动⼩、噪声低，性能稳定、安全可靠。
                                                            heat  dissipation.  The  end  cover  is  made  of  cast  iron,  with  stable
        4.超⾼的击穿扭矩，最⼤切割功率。                                   structure, low vibration, low noise, stable performance, safety and
        5.IP65防护等级，防⽌⽊屑和刨花引起的粉尘问题                           reliability.
                                                            4. Ultra high breakdown torque and maximum cutting power.
                                                            5. IP65 protection grade to prevent dust problems caused by wood
                                                            chips and shavings




         海拔不超过1000m；(⼤于1000m海拔属于⾼原电机，可定制)                    The  altitude  does  not  exceed  1000m;  (more  than  1000m  altitude
         最⾼环境温度不超过40℃(＞40℃可定制)；                              belongs to the plateau motor, can be customized)
                                                             The maximum ambient temperature does not exceed 40 °C;
         最低环境温度不超过15℃(低于-15℃可定制)；
                                                             The minimum ambient temperature does not exceed -15 °C;
         S1⼯作制；                                              S1 working system;
         电源电压波动不超过±5%(短时允许10%)；频率波动不超过±2%；                   The power supply voltage fluctuation does not exceed ± 5% (10%
                                                             is  allowed  for  short  time);  the  frequency  fluctuation  does  not
         绝缘等级F级；
                                                             exceed ± 2%;
         防护等级：IP65；                                          Insulation class F;
         冷却⽅式：IC411；                                         Protection level: IP65;
                                                             Cooling method: IC411;

        技术数据(Technical Data)

                    额定功率    电 压     频率    额定功率 额定转速       效 率  功率因数 额定转矩 堵转转矩 最⼤转矩           堵转电流    重 量
            型  号     Rated    Voltage  Frequency  Rated    Rated  Efficiency  Power   Rated  倍数  倍数  倍数  Weight
            Type    Output                Current  Speed   η     factor  Torque                       kg
                      kW      V      Hz     A     min -1   %     COSφ    Nm     Ts/Tn  Tmax/Tn  Is/In
          YM-634-4   0.37    380     50    1.15   1330    66.0   0.74   2.66    2.1    2.2     4.4    5.3
