BLACKCOMB
BLACKCOMB
5.1
BLACKCOMB
6.1
BLACKCOMB 4.1
Series
BLACKCOMB RACK-MOUNT UV BLACKCOMB

• Integral filter design with o-ring groove for service without the need to drain the water
fail-safe installation, higher operating (10 year limited warranty on UV reactors)
pressure (120 psi), and single manifold heads • Flow rates stated at 95% UVT at a UV dose
(NO POTENTIAL LEAKS BETWEEN HEADS) of 30 mJ/cm 2
• LB4 models now include integral LED lamp • Coated UV lamps for consistent UV output
countdown timer as standard throughout life, 9,000 hour LP lamps,
10,000 hours LP-HO lamps
INTEGRAL FILTER • LB5/6 systems include LIGHTLOCK TM • Splash-proof controller with constant
technology for protected lamp sales
HEAD DESIGN • 316L stainless steel, axial flow reactors allow current electronic ballast
for optimum efficiency & lamp and sleeve

IMAGE FLOW RATE MODEL PORTS LAMP SLEEVE HOUSING HOUSING SHIPPING
2
WEIGHT
1
LB4-Z1 1” 5 micron
8 GPM LB5-Z1 MNPT RL-420 RQ-420 sediment N/A
LC-105
(30.3 lpm) 11.36 kg
(25 lbs)
(1.82 m /hr.) LB4-Z1-NC As above but sold without cartridges
3
LB4-Z1
LB5-Z1-NC As above but sold without cartridges
LB4-Z2 1” 5 micron
8 GPM LB5-Z2 MNPT RL-420 RQ-420 sediment N/A
(30.3 lpm) LC-205 12.45 kg
(1.82 m /hr.) LB4-Z2-NC As above but sold without cartridges (27.4 lbs)
3
LB5-Z2-NC As above but sold without cartridges
LB4-Z12 1” 5 micron Carbon
LB5-Z2 8 GPM LB5-Z12 MNPT RL-420 RQ-420 sediment LC-20C 18.45 kg
LC-105
(30.3 lpm)
(1.82 m /hr.) LB4-Z12-NC As above but sold without cartridges (40.6 lbs)
3
LB5-Z12-NC As above but sold without cartridges
LBH4-Z2 1” 5 micron
15 GPM LBH5-Z2 MNPT RL-420HO RQ-420 sediment N/A
LC-205
12.82 kg
(56.8 lpm) (28.2 lbs)
(3.4 m /hr.) LBH4-Z2-NC As above but sold without cartridges
3
LB4-Z12 LBH5-Z2-NC As above but sold without cartridges
LBH4-Z12 1” 5 micron Carbon
15 GPM LBH5-Z12 MNPT RL-420HO RQ-420 sediment LC-20C
(56.8 lpm LC-105 18.82 kg
(3.4 m /hr.) LBH4-Z12-NC As above but sold without cartridges (41.4 lbs)
3
LBH5-Z12-NC As above but sold without cartridges
LBH4-Z22 1” 5 micron Carbon
15 GPM LBH5-Z22 MNPT RL-420HO RQ-420 sediment LC-20C
(56.8 lpm) LC-205 20.18 kg
(3.4 m /hr.) LBH4-Z22-NC As above but sold without cartridges (44.4 lbs)
3
LBH5-Z22 LBH5-Z22-NC As above but sold without cartridges
REPLACEMENT COMPONENTS
LC-105 Filter cartridge, 50/5 µm sediment, 10” x 4-1/2”, NSF
LC-205 Filter cartridge, 50/5 µm sediment, 20” x 4-1/2”, NSF
LC-20C Filter cartridge, 25 µm carbon taste & odour, 20”x 4-5/8”, NSF
310177 O-ring for new style housings (Systems prior to 2017, order PN# 310142)
160021 Filter wrench for new style housings
510035 RACK mount parts kit
