Page 32 - 变频泵样本

www.chinashenneng.com

不锈钢五通 STAINLESS STEEL 光伏控制器 SOLAR
CONTROLLER
FIVE-WAY

NEW

G1" G1.25" G1.5" G2"

Descriptions/描述
不锈钢五通采用304不锈钢制造，自带逆止阀芯，独有的密封结构设计 Stainless steel five way is made of 304 stainless steel, built-in non-
与橡胶材料选用，使产品具备了适应更加恶劣工况及更加苛刻条件的特 return valve core, unique sealing structure design and rubber
点。专为变频恒压供水系统设计的五通结构，更是将压力传感器、压力 material selection, make the product adapt to the worse working
罐、压力表高度集成，使用户安装更省心，系统更简洁。完全符合欧盟 conditions and more stringent conditions. Designed for variable
和美国等国家对产品安全和环保的超高制造标准与要求，消除了用户对 frequency constant pressure water supply system of five structure,
安全与健康的担忧，在家庭供水系统上具有得天独厚的优势！ also will highly integrated pressure sensors, pressure tank, pressure
gauge, for more easy installation, system cleaner. Fully compliance
with the EU and America and other countries high standards and
Technical parameters/技术参数 requirements for product safety and environmental protection,
eliminates the users worry to safety and health, has a unique
进出水口口径(英寸)Inlet and outlet diameter(Inch) G1" G1.25" G1.5" G2" potential in the domestic water supply system!

PRESSURE
压力传感器 SENSOR PX pressure sensor series/PX系列传感器
PX系列传感器适用于多种严苛介质，其中包括制动液、机油、自来水、
液压油及压缩空气。较大的工作温度范围、高达IP69K的防护等级以及
100V/m的辐射抗扰度确保该系列传感器能够在恶劣的工作环境中保持
可靠的性能。
The PX series sensors are suitable for many kinds of harsh mudiums Descriptions/描述
90° 180° including brake fluid, machine oil, tap water, hydraulic oil, compressed air.
The High working temperature, the IP grade reached to IP69K and 100V/m 1. 全铝制金属外壳，无风扇设计：使用寿命更高，散热效果更好; 1. All-aluminum metal casing, non-fan design; with the longer using life and the better
rediated sure this series sensors could keep the reliavble performance in the heat dissipation effect;
harsh working conditions. 2. 更友好的人机交互界面：电流、电压、功率、转速任意切换; 2. More friendly human-computer interaction interface: arbitrary switching of current,
3. 太阳能板组件成本更低，效率更高：>99%追踪效率的MPPT算
voltage, power and speed;
Good EMC protection/良好的电磁兼容(EMC)性 Operating temperature range/工作温度范围 法，相较于传统的PWM控制算法，能提高30%的太阳能利用率； 3. Solar panel components are cheaper, but more efficient: the MPPT algorithm with
4. IP65防护等级：具备全天候，全环境的使用条件；
确保产品不会被环境电磁干扰损坏。辐射抗扰度可达100V/m 经过补偿的工作温度范围为-40℃到125℃（-40℉到257℉），一款传 tracking efficiency greater than 99% which increase the solar energy utilization rate
（ISO11452-2标准）。 感器即可适用于多种不同应用。 5. 全方位的电机保护功能：过压、欠压、过流、过温、短路、缺相、 by 30% compared with the traditional PWM control algorithm;
干转等。 4. IP65 protection degree: with al-weather, all-environmental use conditions;
Make sure the products will not be damaged by environmental electromagnetic A compensated operating temperature range -40℃ to 125℃(-40℉ to 257℉] 5. Comprehensive motor protection functions: Over-Voltage, Under-Voltage, Over-
interference.Radiated immunity protection up to 100V/m(ISO 11452-2). allows customers to design the same sensor in variety applications. Current, Over-Temperature, Short Circuit, Phase Loss, Dry Running, etc.
PRESSURE
压力表 GAUGE
配套太阳能光伏板参数 Parameters of the supporting solar panel
防护等级
输入功率
最大电流
型号 Input power Max. current Protection level
Model (kW) (A) (IP) 开路电压范围 配板功率 推荐配板功率
Technical parameters/技术参数 Open circuit voltage range(V) Solar panel power(kW) Recommended solar panel power(W)
SC-01/D24-370 0.37 15 65 ＜75 0.55 2x275W并接(in parallel)
尺寸规格 油浸式 全不锈钢 压力范围
Φ50 Φ60 防震设计 外壳 0-11bar SC-01/D48-370 0.75 15 65 ＜100 1.2 2x300W串接(in series)+2x300W并接(in parallel)
SC-01/D72-370 1.1 15 65 ＜150 1.8 3x300W串接(in series)+3x300W并接(in parallel)
Size Oil immersed All stainless Pressure range
Φ50 Φ60 Φ50 Φ60 shockproof design steel case 0-11bar SC-01/D96-370 1.5 15 65 ＜200 2.4 4x300W串接(in series)+4x300W并接(in parallel)

PAGE/21 追求卓越的品质，追求完美的产品。 PAGE/22
Seek for excellent quality, Cast on perfect products.
