混凝土基础及槽钢基础安装示意图 Installation diagram of concrete base and channel steel base

注：适用于L1+L7≤2000mm基础的安装。
Note: applicable for the installation of base at L1+L7≤2000mm.
图1 Fig.1

注：适用于2000mm<L1+L7≤3500mm基础的安装。
Note: applicable for the installation of base at 2000mm<L1+L7≤3500mm.
图2 Fig.2

250

100 预留孔
安 Pre-embedded hole
100×200 100×200
25 Installation hole 装 地脚螺栓 Anchor bolt
孔
M18 M18

B1 B+100

(L1+L7-200)/3
L1+L7-200
L1+L7-100
注：适用于L1+L7>3500mm基础的安装。
Note: applicable for the installation of base at L1+L7>3500mm.
图3 Fig.3
